The five measurements that decide whether it fits
| Measurement | What to include | Why it matters |
|---|---|---|
| Width | Widest fixed point and handles | Side-by-side dual drawers can be broad |
| Body depth | Back to front with cable position | Slim models can still project deeply |
| Height | Top surface plus required upper clearance | Under-cabinet placement may be unsuitable |
| Open-drawer reach | Body depth plus fully withdrawn basket | You need a safe landing and loading path |
| Ventilation clearance | Exact rear, side and upper gaps in the manual | Exhaust heat must not be trapped |
Choose the likely capacity first with our air fryer size guide, then reject any model whose full operating envelope does not fit.
Measure the operating space, not the storage space
An appliance can fit under a cabinet when cold but be unsuitable there while running. Include the hot-air exhaust path, basket-removal space and a stable heat-resistant surface. Do not plan to move a hot appliance every time you open the drawer.
Single, side-by-side dual and stacked layouts
- Single baskets often use less width, though large models can be deep.
- Side-by-side dual models trade more width for immediate access to both zones.
- Stacked dual models can reduce width but add height and separate drawer reach.
- Flexible-divider trays may be broad even when marketed as one or two zones.
Use the single-vs-dual-basket comparison to decide which footprint solves your meal pattern.
Real model examples—not universal templates
Nutricook publishes the AFS200 at 26.5cm wide and 46.5cm deep, illustrating a narrow but deep layout. Philips publishes the NA350/00 at approximately 38.3cm wide, 44.4cm deep and 31.4cm high. These figures apply to those exact models and should be rechecked before purchase.
Drawer access checklist
- Mark the body footprint with removable tape.
- Add the fully open drawer reach from the manual or a verified measurement.
- Open nearby doors, drawers and the dishwasher to find collisions.
- Confirm the basket can be placed on a heat-safe surface without crossing a walkway.
Socket, plug and cable planning
The correct socket must be reachable without stretching the cable across a sink, hob or counter edge. Confirm the exact 220–240V regional model and appropriate Type-G plug. Do not design the space around a travel adaptor or overloaded extension lead.
Ventilation and heat
Clearance differs by design, so use the manual rather than a generic gap. Keep vents away from walls, soft furnishings and items that can be damaged by heat or moisture. Never block the air inlet or exhaust.
Small-kitchen decision checklist
- Prefer usable basket floor area over the largest litre claim.
- Check whether width or depth is your true constraint.
- Include upper cabinet height and exhaust direction.
- Check storage for racks, divider and spare crisper plates.
- Verify replacement baskets are available for the exact regional model.
Final recommendation
Create a paper footprint that includes the open drawer, then compare it with your actual cooking zone. The best capacity is the one that fits safely in operating position and still serves your normal food.
